Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Application | Data Acquisition ; Testing ; Energy Management ; Automation ; Monitoring |
| Connection to Host | Backplane |
| Contact Form | Reed Relay |
| Current, Leakage | 1 mA @ 60 VDC |
| Depth | 0.197" (5mm) |
| Dimensions | 82.55 x 18.29 x 90.17 mm |
| For Use With | SNAP PAC System |
| Input Current | 3 A |
| Isolation Voltage | 4000 V |
| Length | 3.25" (82.55mm) |
| Maximum Operating Temperature | 70 °C |
| Minimum Operating Temperature | 0 °C |
| Module Type | Output |
| Mounting Type | DIN Rail Mount |
| Number of Channels | 4 |
| Number of I/O Ports | 4 |
| Number of Outputs | 4 Output |
| Operating Temperature | 0 to 70 °C |
| Output | 5 to 60 VDC |
| Output Current | 50 mA |
| Output Type | Digital |
| Output, Range | 5 to 60 VDC |
| Primary Type | Control |
| Product Header | Snap Digital Output Module |
| Resistance, Input | 220 Ohms |
| Series | |
| Special Features | Optical Isolation |
| Standards | UL Listed, CE Marked |
| Supply Voltage | 5 VDC |
| Temperature Operating Range | 0 to 70 °C |
| Time, Turn-Off | 100 μS |
| Time, Turn-On | 100 μs |
| Type | Output |
| Voltage, Operating | 5 to 48 VDC (Nom.) |
| Width | 0.72" (18.29mm) |
Overview
220 Ohms Input Resistance, 0 to 70°C Operating Temperature, Snap Digital Output Modules
These output modules are used to switch up to four separate AC or DC loads. Output modules that are fused use a standard fuse with a convenient handle for easy replacement. The dry contact modules allow switching of low power signals where signal integrit
