Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Application | Data Acquisition ; Energy Management ; Industrial Automation ; Monitoring ; Testing |
| Connection to Host | Backplane |
| Depth | 0.197" (5mm) |
| Dimensions | 82.55 x 18.29 x 90.17 mm |
| For Use With | SNAP PAC System |
| Input | 18 to 32 VDC |
| Input Current | 50 mA |
| Input Type | Digital |
| Input Voltage | 28 VDC (Nom.) |
| Isolation Voltage | 4000 V |
| Length | 3.25" (82.55mm) |
| Maximum Operating Temperature | 70 °C |
| Minimum Operating Temperature | 0 °C |
| Module Type | Input |
| Mounting Type | 5 Pin I/O Mounting Board |
| Number of Channels | 4 |
| Number of I/O Ports | 4 |
| Number of Inputs | 4 Input |
| Primary Type | Control |
| Product Header | Snap Digital Input Module |
| Series | |
| Special Features | Optical Isolation |
| Standards | UL and CE Approved |
| Supply Voltage | 5 VDC |
| Temperature Operating Range | 0 to 70 °C |
| Time, Turn-Off | 0.025 ms |
| Time, Turn-On | 0.025 ms |
| Type | Input |
| Voltage Rating | 18 to 32 VDC |
| Width | 0.72" (18.29mm) |
